| Name |
Length |
Diameter |
Efficiency |
Primary Application |
Application Note |
descripton |
| Inner |
Outer |
90% |
Beta 75 |
| P560713 |
10.04" (255 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
3 Micron |
3 Micron |
PTI PG080-GU-B |
|
Element assy, PTI/Mahle, 3 micron absolute, 10'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560714 |
10.04" (255 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
6 Micron |
6 Micron |
PTI PG080-HU-B |
|
Element assy, PTI/Mahle, 6 micron absolute, 10'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560715 |
10.04" (255 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
25 Micron |
25 Micron |
PTI PG080-JUB |
|
Element assy, PTI/Mahle, 25 micron absolute, 10'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560716 |
14.59" (373 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
3 Micron |
3 Micron |
PTI PG120-GU-B |
|
Element assy, PTI/Mahle, 3 micron absolute, 14.7'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560717 |
14.59" (373 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
6 Micron |
6 Micron |
PTI PG120-HU-B |
|
Element assy, PTI/Mahle, 6 micron absolute, 14.7'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560718 |
14.69" (373 mm) |
1.87" (48 mm) |
3.29" (84 mm) |
25 Micron |
25 Micron |
PTI PG120-JUB |
|
Element assy, PTI/Mahle, 25 micron absolute, 14.7'' long, 3000 psi collapse, temperature range -4F to +212F (-20C to +100C) |
| P560719 |
8.27" (210 mm) |
2.03" (52 mm) |
3.9" (99 mm) |
25 Micron |
25 Micron |
MP FILTRI, CU250-A10N |
|
Element assy, MP Filtri, 10 micron absolute, 8.3'' long, temperature range -4F to +212F (-20C to +100C) |
| P560720 |
9.84" (250 mm) |
2.99" (76 mm) |
5.02" (130 mm) |
25 Micron |
25 Micron |
MP FILTRI, CU630-A25N |
|
Element assy, MP Filtri, 25 micron absolute, 9.8'' long, temperature range -4F to +212F (-20C to +100C) |
