Flanged — Stainless Steel-ANSI 150

• Part No.
• 0104090103
• Manuf. No.
• Standard Pack Quantity
• 1

• For prices and availability please Register or add to cart and submit as enquiry.
• 　
• EACH

Description

Features

• CF8M Stainless Steel
• 200psi
• Test pressure: Shell 450psi

Specifications
• ANSI 150

Name	C mm	D mm	G mm	H mm	L mm	NB mm	Size Inch	T mm	W mm
VALVE GLOBE S/S ANSI 150 FLANGED 15NB	60.5	89	35	168	108	15	1/2	11.1	140
VALVE GLOBE S/S ANSI 150 FLANGED 20NB	70	98	43	168	117	20	3/4	11.1	140
VALVE GLOBE S/S ANSI 150 FLANGED 25NB	79.5	108	51	173	127	25	1	11.1	140
VALVE GLOBE S/S ANSI 150 FLANGED 32NB	98.5	127	73	200	165	32	1 1/2	14.3	160
VALVE GLOBE S/S ANSI 150 FLANGED 40NB	120.5	152	92	230	203	40	2	15.9	200
VALVE GLOBE S/S ANSI 150 FLANGED 50NB	120	140	18	135	216	50	2 1/2	17.5	175
VALVE GLOBE S/S ANSI 150 FLANGED 80NB	130	150	127	147	241	80	3	19.1	185
VALVE GLOBE S/S ANSI 150 FLANGED 100NB	155	175	157	292	100	100	4	23.9	210
