FLAT SHACKLE(BK700)

• Part No.
• 0202010109
• Manuf. No.
• Standard Pack Quantity
• 1

Description

Working load limited:55t-1500t.
High quality structural alloy steel.
Proof testing losad:2times 55t-300t 1.5times 400t 1.33times 500t-1500t
The minimum breaking load is 4 times of the rating workingload.
Manufacturing method of the shackle used the swaging and open die forging.
Heat freatment.
Non-destructive testing covered all the products.
Every shackle has the working load mark.
No need to use the lantern ring when the shackle was
connected with highstrength lifting belt,wire rope sling and large radius's domed roof.
Staying quality of the wire rope sling has improved obviously.
The shackle noumenon was galvanized and the pin roll is blue.
Blue pin is the original product's quality mark of Juli.
