MODEL YSD2 HYDRAULIC STEEL WIRE ROPE SLING PRESSED MACHINE

  • Part No.
  • 0210010200
  • Manuf. No.
  • Standard Pack Quantity
  • 1
  • For prices and availability please Register or add to cart and submit as enquiry.
  • 　
  • EACH

Description

Advancement of the pressed sling made by Hydraulic Steel Wire Rope Sling Pressed Machine: High joint strength, high working load limit, strong corrosion resistance; to save the cost of steel wire rope; precise length, advanced technology, high efficiency; resolve the limited space of the lifting operation.

  • Max. Force
  • YSD2-1500(15000 kn) ;YSD2-2000(20000 kn);
  • Max. Diameter In One Pressing
  • YSD2-1500(Φ46 mm) ;YSD2-2000(Φ65 mm);
  • Max. Diameter In Multi- Pressing
  • YSD2-1500(Φ46 mm) ;YSD2-2000(Φ81 mm);
  • Max Piston Movement
  • YSD2-1500(220 mm) ;YSD2-2000(220 mm);
  • Piston Working Movement
  • YSD2-1500(200 mm) ;YSD2-2000(200 mm);
  • Max. Working Pressure
  • YSD2-1500(24 mpa) ;YSD2-2000(31.5 mpa);
  • Total Length
  • YSD2-1500(3500 mm) ;YSD2-2000(3500 mm);
  • Total Height
  • YSD2-1500(2710 mm) ;YSD2-2000(2710 mm);
  • Total Width
  • YSD2-1500(1150 mm) ;YSD2-2000(1150 mm);
  • The Up Speed Of Piston
  • YSD2-1500(10 mm/sec) ;YSD2-2000(10 mm/sec);
  • The Down Speed Of Piston
  • YSD2-1500(10 mm/sec) ;YSD2-2000(10 mm/sec);
  • Power
  • YSD2-1500(22 kw) ;YSD2-2000(30 kw);
  • Voltage
  • 50Hz 380V
  • Weight
  • YSD2-1500(1700 kg) ;YSD2-2000(1700 kg);
  • Color
  • BLUE
