MODEL YSD1 HYDRAULIC STEEL WIRE ROPE PRESSED MACHINE
- Part No.
- 0210010100
- Manuf. No.
- Standard Pack Quantity
- 1
Description
Advancement of the pressed sling made by Hydraulic Steel Wire Rope Sling Pressed Machine: High joint strength, high working load limit, strong corrosion resistance; to save the cost of steel wire rope; precise length, advanced technology, high efficiency; resolve the limited space of the lifting operation.
- Max. Force
- YSD1-300(3000 kn) ;YSD1-500(5000 kn); YSD1-1000(10000 kn)
- Max. Diameter In One Pressing
- YSD1-300(Φ25 mm) ;YSD1-500(Φ32 mm); YSD1-1000(Φ44 mm)
- Max. Diameter In Multi- Pressing
- YSD1-300(Φ42 mm) ;YSD1-500(Φ42 mm); YSD1-1000(Φ56 mm)
- Max Piston Movement
- YSD1-300(80 mm) ;YSD1-500(95 mm); YSD1-1000(220 mm)
- Piston Working Movement
- YSD1-300(70 mm) ;YSD1-500(85 mm); YSD1-1000(185 mm)
- Max. Working Pressure
- YSD1-300(25 mpa) ;YSD1-500(28 mpa); YSD1-1000(28 mpa)
- Total Length
- YSD1-300(1600 mm) ;YSD1-500(1680 mm); YSD1-1000(2080 mm)
- Total Height
- YSD1-300(1620 mm) ;YSD1-500(1720 mm); YSD1-1000(2180 mm)
- Total Width
- YSD1-300(600 mm) ;YSD1-500(620 mm); YSD1-1000(1130 mm)
- The Up Speed Of Piston
- YSD1-300(4.8 mm/sec) ;YSD1-500(3.6 mm/sec); YSD1-1000(3.8 mm/sec)
- The Down Speed Of Piston
- YSD1-300(25 mm/sec) ;YSD1-500(22 mm/sec); YSD1-1000(24 mm/sec)
- Power
- YSD1-300(7.5 kw) ;YSD1-500(7.5 kw); YSD1-1000(11 kw)
- Weight
- YSD1-300(2300 kg) ;YSD1-500(3100 kg); YSD1-1000(7400 kg)
